| Part No. 零件号 | I.D. 软管内径 | O.D 软管外径 | MAX W.P. 最大工作压力 | MIN B.P 最小爆破压力 | MIN B.R 最小弯曲半径 | WEIGHT 参考重量 | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| inch | mm | Min (mm) | Max (mm) | Mpa | psi | Mpa | psi | mm | Kg/m | |
| HL994-01-04 | 1/4" | 6.3 | 12.0 | 13.4 | 2.4 | 350 | 10 | 1400 | 76 | 0.13 |
| HL994-01-05 | 5/16" | 7.9 | 13.9 | 15.5 | 2.4 | 350 | 10 | 1400 | 76 | 0.15 |
| HL994-01-06 | 3/8" | 9.5 | 15.8 | 17.3 | 2.4 | 350 | 10 | 1400 | 76 | 0.22 |
| HL994-01-08 | 1/2" | 12.7 | 19.0 | 20.6 | 2.1 | 300 | 8 | 1200 | 127 | 0.26 |
| HL994-01-10 | 5/8" | 15.9 | 22.5 | 24.1 | 2.1 | 300 | 8 | 1200 | 152 | 0.35 |
| HL994-01-12 | 3/4" | 19.1 | 25.5 | 27.1 | 2.1 | 300 | 8 | 1200 | 177 | 0.37 |
| HL994-01-16 | 1" | 25.4 | 32.0 | 35.0 | 1.4 | 200 | 6 | 800 | 254 | 0.66 |
