HL20791-T

90° national standard metric internal thread 74° internal conical surface

Introduction： High reliability: The hydraulic system can operate stably under high pressure and high load conditions. The design and manufacturing process of the parts ensure their robustness and durability, capable of withstanding considerable pressure and impact, and reducing the possibility of failure. It has fatigue resistance and large displacement compensation capacity, and is widely used in pipeline systems for media such as oil and water
Telephone： 400-100-6819
Email： info@huvlone.com

Product Inquiry

Service Hotline 400-100-6819

Service Hotline： 400-100-6819

商品名称: HL20791-T

代号 PA RT NO.	螺纹T	软管			尺寸
代号 PA RT NO.	THREAD T	公称内径DN	标号 DAHLH		L	H		S1
HL20791-12-04	M12X1.5	6	04		32	30		17
HL20791-14-04T	M14X1.5	6	04		30	30		17
HL20791-14-05	M14X1.5	8	05		33	37		19
HL20791-14-06	M14X1.5	10	06		36.5	38.5		19
HL20791-16-04T	M16X1.5	6	04		32	32.5		19
HL20791-16-05T	M16X1.5	8	05		33	36		19
HL20791-16-06	M16X1.5	10	06		36.5	39.5		22
HL20791-18-05T	M18X1.5	8	05		33	38.5		22
HL20791-18-06T	M18X1.5	10	06		36.5	40.5		22
HL20791-22-08T	M22X1.5	13	08		43.5	46.5		27
HL20791-27-08T	M27X1.5	13	08		43.5	48.5		32
HL20791-27-10T	M27X1.5	16	10		55	53		32
HL20791-30-10T	M30X1.5	16	10		55	54		36
HL20791-30-12T	M30X1.5	19	12		64	62		36
HL20791-33-12T	M33X2	19	12		64	61		41
HL20791-36-12T	M36X2	19	12		64	57		41
HL20791-36-14T	M36X2	22	14		68.5	63		41
HL20791-36-16T	M36X2	25	16		74	64		41
HL20791-39-16T	M39X2	25	16		74	66		46
HL20791-45-20T	M45X2	32	20		91.5	78.5		55
HL20791-52-24T	M52X2	38	24		109	92		60
注:1、表中代号用于编织软管。2、如需用于缠绕软管代号改为HL20792-XX-XX。
